Flynn's taxonomy

overview

classification of computer architectures (1966)

• since the rise of CPUs

  • a multiprogramming context evolved as an extension of the system

    4 initial classifications based upon the number of concurrent instruction streams

    • and datastreams available in the architecture

background

Bandwidth is an expression of time-rate of occurence

• computational or execution bandwidth
  • is the number of instructions processed per second
• storage bandwidth
  • is the retrieval rate of operand and operation memory words (words/second)

Latency or latent period is the total time associated with processing

• of a data unit at a phase in the computing process

  • the ratio of the number of simulataneous instructions being processed
    • to this constrained multiplicity is called the Confluence
      • or concurrence of the system

single instruction stream, single data stream SISD

• sequential computer which exploits no parallelism in either the instruction or datastreams

• single control unit (CU) fetches a single instruction stream (IS) from memory

  • CU generates appropriate control signals to direct a single processing element (PE) to operate on a single data stream (DS) one operation at a time



single instruction stream, multiple data streams SIMD

• a single instruction is simultaneously applied to different data streams
  • instructions can be executed sequentially (pipelining)

    • or in parallel by multiple functional units

      SIMD is broken down into 3 categories

      array processor known as SIMT

      • recieves same instruction
        • but each parallel processing unit
          • has its own distinct memory and register file

      pipelined processor

      • recieves the same instruction
        • but then read data from a central resource
          • each processes fragments of that data
            • then writes back results to same central resource

      associative processor

      • recieves the same instruction
        • but in addition a register value
          • from the CU is also broadcast to each PU
            • in each PU an independent decision is made
              • based on data local to the unit
                • comparing against the broadcast value
                • as to whether perform the broadcast instruction, or to skip it

multiple instruction streams, single data stream

• uncommon architecture
  • generally used for fault tolerance
• heterogeneous system operate on the same data stream
  • and must agree on the result

e.g. Space Shuttle Flight Control Computer

multiple instruction streams, multiple data streams

• includes multi-core superscalar processors
  • and distributed systems
    • using either one shared memory space or a distributed memory space

Duncan's taxonomy
